goods lift

Cargo lift Cibes A8000 is powerful enough to lift 1000 kg and large enough to transport goods pallets and pallet trucks, or groups of 8-10 people.

Delivered in ready-made modules
Low lift pit and top height
Installation in 4-5 days

Powerful GOODS LIFT with attendant

The generous platform sizes and high load capacity make goods lift Cibes A8000 our most powerful and versatile lift. The Cibes A8000 is a lift certified for safe transport of both goods and passengers, also known as a goods lift with attendant. This means that staff members are allowed to accompany the cargo while the lift is travelling.

In addition, the Cibes A8000 has a much smaller footprint than a conventional lift and can be installed in less than a working week. Contact us today for a free quotation!

GOODS LIFT CIBES A8000 (1000 KG)

All-inclusive lift concept

The lift is delivered in ready-made elements with everything you need for installation, including the lift shaft.

Rated load of 1000 kg

The large capacity makes the Cibes A8000 suitable for most public and commercial buildings, such as warehouses, shops, offices and museums.

Minimal structural impact

The low pit and headroom, ready-made shaft and integrated machine room of the Cibes A8000, minimise the structural impact on your building.

Installation in 4-5 days

Our ready-made lift concept speeds up the installation and reduces the need for structural adaptation.

MACHINE ROOM LESS

All of the screw-driven machinery and electrics fit inside the cargo lift. No need for a separate machine room.

130 mm lift pit

The Cibes A8000 lift can be installed with a floor recess of just 130 mm, or directly on the floor if you add an access ramp.

2350 mm headroom

Thanks to its smart and space-saving construction, goods lift Cibes A8000 requires a headroom of only 2350 mm.

Commercial lift solution

This Cibes A8000 lift is used for merchandise and passenger transport by one of Sweden’s most renowned kitchen suppliers, Marbodal. Press play to step inside the lift and get a better look!

Overview of goods lift Cibes A8000

The Cibes A8000 is a large and powerful lift for passengers and merchandise that is surprisingly space-efficient. In fact, an amazing 70% of the total footprint of the goods lift is constituted by the lifting platform, which means that the Cibes A8000 makes great use of your space. The Cibes A8000 also offers you many great practical features and hard-wearing options that guarantee that your lift will last and look good for many years.

Cibes A8000 technical data

Rated load: 1000 kg
Power supply: 3 × 230 VAC/3 × 400 VAC, 50 Hz, 16 A, 5 × 2,5 mm²
Speed: max 0.15 m/s
Min headroom: 2350 mm (full-height door)
Lift pit: 130 mm or 0 mm with access ramp
Max travel: 13 m
Max number of stops: 6

Note: The floor cut out may vary depending on lift configuration. For exact measurements, please ask Cibes for project specific drawings.

ASK FOR A FREE QUOTATION

Lift SIZES & CUT OUT sizes

Platform size (w x d, mm)	Cut out size (w x d mm)*
1105 x 2180 mm	1595 x 2310 mm
1405 x 1980 mm	1895 x 2110 mm
1405 x 2480 mm	1895 x 2610 mm

*Cut out size = the minimum size of the lift pit on the bottom floor and the minimum opening for the lift through the floors.

Extra wide lift doors

The doors of cargo lift Cibes A8000 have a clear opening width between 1000 and 1300 mm, depending on the lift size. This makes it easy to transport all kinds of items.

EI60 fire rated lift doors

The Cibes A8000 offers you the choice between standard steel doors and EI60 fire rated doors with a small vision panel or with panoramic glazing.

Hard-wearing floor

Aluminium checker plate is is sturdy and resistant. The perfect floor choice for any goods lift.

Raised platform edges

Raised platform edges will protect the shaft walls against damage from trolleys and pallet-trucks.

Kick-plates in stainless steel

Kick-plates in stainless steel will protect the doors of your platform lift from dents and scratches.

All-inclusive lift concept

Cargo lift Cibes A8000 is delivered in ready-made elements for fast and easy installation.

All-inclusive lift concept ready to assemble
Ready-made lift shaft in steel or glass panels
Speedy installation, low construction costs

CE MARKED

Our lifts are type certified by the notified body Liftinstituut B.V. and are allowed to carry the CE mark.

SWEDISH QUALITY EST 1947

Cibes Lift was founded in 1947 and our lifts have been designed and manufactured in Sweden ever since.

SAFE & EASY TO USE

Our lifts meet the high and exacting requirements of European safety standards and are safe and easy to use.

ECOLABEL LISTING

The Cibes A8000 is listed in the database for building products that can be used in Nordic Swan Ecolabelled Buildings.

DESIGN with colour

Use colour to make the most of your lift design! Choose between more than 250 RAL colours or compose your unique colour scheme with the elegant shades of our exclusive colour guide.

Download colour guide

Examples of other applications

Thanks to its compact and ready-made construction, the Cibes A8000 is a very cost-efficient lift solution compared to conventional lifts of equivalent capacity. In addition, the certification for transport of passengers and merchandise, makes the Cibes A8000 an ideal solution for a wide range of buildings and applications.
