Cibes B385 Technical Data
- Rated load: 385 kg
- Power supply: 1 × 230 VAC, 50 Hz, 16 A
- Speed: max 0.06 m/s
- Lift pit: 60 mm or 0 mm with access ramp
- Max travel: 3 m
- Max number of stops: 2
- Access: Straight-through/adjacent
- Installation: Indoor/outdoor
Note: The external dimensions and cut out sizes may vary depending on lift configuration. For exact measurements, please ask Cibes for project specific drawings.
ASK FOR A FREE QUOTATION
Lift Sizes & Critical Measurements
Platform sizes (w x d, mm) |
External dimensions
(w x d, mm) |
Cut out size for pit
(w x d, mm) |
900 × 1400 mm |
1310 × 1520 mm |
1370 × 1580 mm |
900 × 1600 mm |
1310 × 1720 mm |
1370 × 1780 mm |
1100 ×1400 mm* |
1510 × 1520 mm |
1570 × 1580 mm |
1100 × 1600 mm |
1510 × 1720 mm |
1570 × 1780 mm |
*Platform size available with adjacent access (90° access). With adjacent access, the available floor space on the platform is reduced to 1100 x 1360 mm.
Note: The Cibes B385 must be installed on a cast concrete foundation, able to withstand a load of min 800 kg. If the lift is placed between two walls, a safety distance must be added. Contact your Cibes dealer for more information.
