All-inclusive lift concept
The lift is delivered in ready-made modules with everything you need for installation, including the lift shaft.
Platform lifts
Cibes A5000
Cibes A5000 platform lift
The Cibes A5000 is our most popular lift model. The space-saving lift footprint and robust construction, paired with innovative Scandinavian design enables the lift to adapt for accessibility and application in both public and private home environments.
Modular A5000 platform lift
With eight different platform sizes to choose from, and the capability of withholding a load of 4-5 people (400-500kg), the A5000 platform lift model is designed to fit seamlessly into any building. Whether your property is new or old, the A5000 can be customised from the footprint, down to finishing touches to suit your environment’s aesthetics.
Cibes A5000 (400/500 kg)
Energy efficient
Ideal for use with single-phase power, or three-phase power if required.
Space-efficient lift solution
The passenger platform is 70% of the overall footprint. A great use of space!
Installation in 2-3 days
Our ready-made lift concept speeds up the installation and minimises the impact on the building.
What is a platform lift?
Do you know what makes platform lifts different from conventional lifts? This video explains all the essentials.
The Cibes A5000 platform lift is our most popular platform lift and for good reasons. With the standard size of an A5000 accommodating to wheelchair users and can fit a young child’s stroller. the lift has potential for numerous applications from:
- Businesses and office buildings.
- Flats and apartments.
- Public facilities: shopping centres, supermarkets, libraries, leisure facilities, restaurants and more.
- Private homes.
Cibes Lift is a world-leading manufacturer of screw-driven platform and cabin lift solutions for private and public settings. Our head office, factory and R&D department are located in Sweden, a country known for its smart, high-quality products and environmental awareness.
Specifications and model details
Technical information
- Installation:Indoor
- Rated load:400/500 kg
- Power supply:1 × 230 VAC, 50 Hz, 16 A, min. 3 × 2,5 mm², 3 × 230 VAC/3 × 400 VAC, 50 Hz, 16 A, min. 5 × 2,5 mm²
- Speed:max 0.15 m/s
- Min headroom:2300 mm (full-height door)
- Lift pit:50 mm or 0 mm with access ramp
- Drive system:Screw and nut
- Max travel:15 m
- Max number of stops:6
- Lift controls:One touch (automatic drive) on landings, hold-to-run on platform
- Motor Power:2.2 KW
- Machine room:Integrated (MRL)
- Door configuration:Single access, open-through, adjacent
- Directives and standards:MD 2006/42/EC, EN 81-41
Complete specifications and lift sizes
Check out the full Complete specifications and model details of Cibes A5000.
View specifications
